Basic Info
Model NO: DZ47LE-63
Type: RCBO
Certification: ISO9001-2000, CE CB CCC TIS
Rated Working Voltage: 230/400
Rated Vorking Current: 6;10;16;20;25;32;40;50;63A
Body Color: White
Trademark: SINGI
Electric Life: 4000 times
Mechanical Life: 10000 times
Package: Carton
Poles number: 1P+N,2P;3P;3P+N,4P
Rated frequency: 50/60Hz
Breaking Capacity: 6000KA
Origin: China.
Production Description
Product Description
Model: | RCBO | ||
Type | DZ47LE-63 | ||
Origin | Zhejiang, China | ||
Standard | IEC 1009-1 /GB16917.1 | ||
Electrical features | Reted Current | A | 6;10;16;20;25;32;40;50;63A |
Poles | 1P+N,2P;3P;3P+N,4P | ||
Rated Voltage Ue | V | 230/400 | |
Isolation voltage Ui | V | 600 | |
Rated frequency | Hz | 50/60 | |
Rated breaking capacity | A | 6000a | |
Tripping Type | C type, D type | ||
Mechanical features | Heat resistance category | 2 | |
Protection Class | IP 20 | ||
Pollution degree | 2 | ||
Electrical life | 4000 | ||
Machanical life | 10000 | ||
Ambient temperature | -5 ~ + 35 | ||
Terminal connnection type | Cable/Pin -type busbar | ||
Installation | Mounting | 35mm DIN rail | |
Wiring | With clamp, Solid cable 16mm2 and below are available |
